GraalVM Deep Dive

Bring the Action: Using GraalVM in Production (recording)

Structure

• GraalVM overview 🐰
• Migrating an app to GraalVM 🤖
  • 👩‍💻 use Native Build Tools 🛠️
  • 👩‍💻 basic performance measurements with time 📈
• Using libraries 📚
  • A library might be designed to be Native-Image friendly out of the box;
  • A library might add config files to its source code;
  • Library configuration can be provided via GraalVM Reachability Metadata Repository;
  • 👩‍💻 You can programmatically generate configuration via framework annotations, such as @ReflectiveAccess (Micronaut)
  • You can use Native Image's Tracing Agent (java -agentlib:native-image-agent -jar ./target/demo.jar)
  • You can provide configuration manually via json.
• Performance optimizations 🚀
  • Overview of compiler optimization levels
  • 👩‍💻 PGO
    • ML-enabled PGO
    • You get LCOV info as a side product of PGO
  • G1 GC
  • -march=native
  • Memory management (xmx)
  • Demo: spring-petclinic
• Testing 👨‍🔬
• Deployment 📦
  • 👩‍💻 Packaging and linking options
    • JDK
    • JDK | Distroless
    • JDK | JLink
    • Native | Dynamic |
      • docker build -f Dockerfiles/Dockerfile.native -t native-spring-boot-native:latest .
      • docker run -p 8080:8080 native-spring-boot-native:latest .
    • Native | Mostly static | Distroless
    • Native | Static | From scratch
    • Native | Static | From scratch | Optimize for size
    • You can significantly reduce the size by going with Native Image:

➜ docker images | grep "native"
localhost/native-spring-boot-static-size            latest         ... ...    58.5 MB
localhost/native-spring-boot-static-scratch         latest         ... ...    84.4 MB
localhost/native-spring-boot-native                 latest         ... ...    125 MB
localhost/native-spring-boot-jdk-jlink              latest         ... ...    126 MB
localhost/native-spring-boot-jdk-distroless         latest         ... ...    218 MB
localhost/native-spring-boot-jdk                    latest         ... ...    480 MB

• Scan the images for vulnerabilities & packages 🛡️
• Buildpacks
• GitHub actions
• Security 🛡️
  • Security by design
  • 👩‍💻 Vulnerability Scanning
    • grype: native-image-inspect --sbom ./target/demo-sbom | grype -v
    • native-image-inspect --sbom ./target/demo-sbom>output.json
  • 👩‍💻 SBOM support: exposing in Spring Actuator
  • 👩‍💻 SBOM support in Micronaut
  • GitHub Action
  • Demo: native-spring-boot-sbom
• Monitoring 📈
  • 👩‍💻 Micrometer
    • (Tempo -> service graph)
  • 👩‍💻 jvmstat
  • JFR, JMX, jcmd
  • perf stat <./target/demo>
• Tooling 🔮
  • 👩‍💻 Build reports
• In the lab 👩‍🔬
  • Some of our research project slogans
    • "Why do it? Because we can"
    • "We do these things not because they are easy, but because we thought they were going to be easy"
  • [Llama3.java]|(https://github.com/mukel/llama3.java)
  • Native Image Layers
  • Project Crema
  • -H:Preserve=all
  • Embedding Python (Pygal charts)
  • Wasm backend for Native Image (javac)
