🚧 FreeCAD Road Workbench

Road is the Transportation and Geomatics Engineering workbench for FreeCAD.

Use with FreeCAD version 1.0 — there is a bug in version 1.1

✨ Features

• Geopoints ✔️
• Terrain ✔️
• Alignment ✔️
• Profile ✔️
• Structure ✔️
• Superelevation ❌
• Road 🔄
• Regions ✔️
• Sections ✔️
• Volume ❌
• GeoLine ❌
• LandXML Importer ✔️
• LandXML Exporter 🔄

📥 Installation

🔹 Option 1: Install via Addon Manager (Recommended)

1. Open FreeCAD.
2. Go to Tools > Addon Manager.
3. In the Addon Manager window, search for Road.
4. Select the workbench and click the Install button.
5. Restart FreeCAD to complete the installation.

🔹 Option 2: Manual Installation

1. Download the latest release the repository.

2. Copy the downloaded folder to your FreeCAD Mod directory:

   Windows: C:\Users\<YourUsername>\AppData\Roaming\FreeCAD\Mod
   Linux(Flatpak): /home/<YourUsername>/.var/app/org.freecad.FreeCAD/data/FreeCAD/Mod
   MacOS: ~/Library/Preferences/FreeCAD/Mod


3. Restart FreeCAD to complete the installation.

💬 Feedback and Support

💡 Need help? Join the discussion on the FreeCAD Forum: FreeCAD Road Workbench.

🐞 Found a bug? Report issues on GitHub.

👨‍💻 Developer

Developed with passion by Hakan Seven (@HakanSeven12) with inspiration and contributions from the FreeCAD community.

📸 Tutorials

📸 Screenshots
